Axon Side DLBS 240, 400 kW DC
Charging station - Power unit
AXON SIDE is a next-gen power unit delivering ultra-fast DC charging for EVs, buses, and trucks. Supporting up to six outputs, it connects seamlessly to multiple satellites for flexible site configurations. With Dynamic Load Balancing (DLBS), it optimizes power use, reducing charge times and ensuring maximum efficiency in high-demand locations.
Smart energy management
Axon Side DLBS is the perfect solution for high-traffic locations, such as expressways, logistics parks, and commercial hubs, where efficient energy management is critical. Its Dynamic Load Balancing System (DLBS) intelligently distributes up to 400 kW of power across 6 connected satellites. Operating in real-time, it ensures every vehicle receives a guaranteed minimum power supply, dynamically reallocates excess power, and minimizes unused capacity. These features reduce charging times, lower operational costs, and enable seamless operation even during peak demand. For Charge Point Operators (CPOs), DLBS represents a smart investment, delivering higher profitability and improved energy utilization.
Let's talk
Customizable charging configurations for optimal performance
The Axon Side DLBS offers flexibility to support various electric vehicles, from personal EVs and fleet vans to e-buses and e-trucks. Depending on the specific needs of the location, operators can design the charging hub with a customized number of CCS1 or NACS connectors, ensuring optimal configuration for the site. Operators can also select the appropriate SAT 400 (3 dual-connector or 6 single-connector units), allowing for tailored, well-balanced charging points that meet the unique requirements of each location. This flexibility ensures efficient and scalable charging for urban centers, fleet depots, and highways.
Let’s talk
Unmatched energy efficiency
Dynamic Load Balancing System (DLBS) in Axon Side is designed to maximize charging efficiency and ensure full use of available station potential. The system intelligently distributes power between connected vehicles, continuously adjusting charging levels based on real-time demand while maintaining a guaranteed minimum power for each EV. By reallocating unused capacity to other vehicles, DLBS reduces energy waste and keeps the charging station operating at optimal performance. This dynamic approach supports shorter charging sessions, improved station throughput, and more efficient use of installed power. For operators, it translates into lower operational costs and better utilization of infrastructure. Combined with optimized energy flow and reduced power losses, DLBS provides a scalable and sustainable solution for high-performance charging hubs.
Let's talk
Specification
Basic data
Max. charging power
240, 400 kW
Device type
Power station
Maximum charging current for single output
500 A
Maximum charging current for all outputs
240 kW - 800 A, 400 kW - 1200 A
Number of outputs
1-6
Granularity of output power
240 kW - 40 kW, 400 kW - 80 kW
Voltage range
150 - 1000 V
Plug & Charge
ready
